Compliance Traceability Index¶
This directory contains requirements traceability matrices mapping regulatory standards to their implementation in Cloud-Native DCS. These documents are intended for FDA auditors, quality assurance teams, and engineers evaluating compliance coverage.
How to Use These Documents¶
- Auditors: Each document maps specific regulatory clauses to their implementation and evidence. Start with the summary table below, then drill into the per-standard document for detailed traceability.
- QA: Use the gap analysis sections to plan validation activities and track progress toward full compliance.
- Engineers: Review coverage status to understand which regulatory requirements are met and where gaps remain.
The models these matrices trace are live objects in the running system.
Compliance Summary¶
| Standard | Scope | Coverage | Status | Detail |
|---|---|---|---|---|
| ISA-88 / IEC 61512 | Batch process control | High | Substantially Implemented | Physical, procedural, recipe, and batch models mapped to CRDs; Part 3 library/transformation and Part 2 scheduling features are implemented at the data-model/controller layer with no UI/API/CLI surface (removed in #480, CRDs retained); named Partial rows remain |
| IEC 61131-3 | Programming languages (SFC, ST) | High | Implemented | SFC engine, ST interpreter, recipe/procedural chart execution |
| IEC 61499 | Function block architecture | — | Migrated off | Not a compliance posture: the product migrated from IEC 61499 to IEC 61131-3 cyclic-scan execution on 2026-03-16; the doc records the migration |
| 21 CFR Part 11 | Electronic records & signatures | High | Substantially Implemented | Immutable audit trail + validating webhook, OIDC auth, HMAC-SHA256 e-signatures, audit archival to TimescaleDB, executable IQ/OQ/PQ. Remaining gaps: two-factor enforcement delegated to the IdP (§11.200(a)(1) Partial) and identification-code/password controls (§11.300(a-b) Planned) |
| GAMP 5 | Computerized system validation (CSV) | High | Category 4 (Configured Product) | Per-layer categorization (infrastructure / configured product / configuration / Category 5 boundary) plus a V-model lifecycle mapping: executable IQ/OQ/PQ, ChangeRequest + e-signatures, and Qualification AuditRecords feed the customer's validation activities |
| ALCOA+ data integrity | FDA/MHRA data-integrity principles | High | Implemented | All nine principles mapped to shipped controls: OIDC-attributed immutable AuditRecords, synchronous timestamping, HMAC-SHA256 record-bound signatures, two-tier retention (etcd + TimescaleDB) with unified query and regulatory export |
| EU GMP Annex 11 | Computerised systems (EU GMP / PIC/S) | High | Substantially Implemented | All 17 clauses of the 2011 text traced; the electronic-record, audit-trail, signature, access and change-management rows derive from the Part 11 matrix, and the lifecycle rows (suppliers, validation, incident management, business continuity, archiving) from the SDL audit file, the executable qualification suite and the drill logs. Organisational clauses (risk management, personnel, periodic review) are N/A with what the product supplies stated |
| ISA 5.1 | P&ID instrumentation symbols | Low | In Progress | 23 symbols across 5 categories |
| ISA-95 / IEC 62264 | Enterprise-control integration | Low | Partial | B2MML mapping, MES integration patterns |
| IEC 62443 | Industrial cybersecurity | Moderate-High | SL-C target { 2 2 2 2 2 2 2 } — FR 3 conditional on SR 3.3 and on SR 3.6 for the raw device write path (#1683); the other named conditionals closed (#971–#974, #977) | Full 51-row SR matrix, clause-verified 2026-07-18 against the purchased ANSI/ISA-62443-3-3 text (#968). Pod security, RBAC, distroless images, cert-manager mTLS, NetworkPolicies enforcing the IEC 62443 zone/conduit model, MQTT TLS+auth+ACL, cosign signing, SBOMs, OPC UA SignAndEncrypt. Clause-verified SL 3 elements: non-repudiation (SR 2.12), audit-information protection (SR 3.9), programmatic audit access (SR 6.1 RE(1)), crypto integrity on IP conduits (SR 3.1 RE(1)); reference cluster runs Talos (immutable node OS, cutover completed 2026-05-12) |
| IEC 62443-4-1 | Secure development lifecycle | Moderate | ML 2 baseline (7 of 8 practices); SVV gap pending external V&V engagement | All 47 requirements assessed 2026-07-18 (#970); SDL practice docs under docs/sdl/ (process/RACI, security-requirements spec, interface catalog + DiD design, secure coding standard, defect + update management); Table 3 tester-independence plan (single external engagement covers SVV-1/2/3/4 + review seats); public wording scoped to "aligned to 62443-4-1 practices" |
| IEC 62443-4-2 | Component technical security requirements | Moderate | Component SL-C 2 self-assessed, with CR 3.3 and CR 3.6 Partial (#1683); the named closures done (#971–#974, #977, #978) | All shipped components classified as software applications (3.1.42); full CR + SAR matrix clause-verified 2026-07-18 (#969); CCSC 2 delegation register documenting every platform-delegated countermeasure (IdP accounts/passwords, etcd at-rest, NTP, admission signature verification, physical segmentation); SAR 3.2 malicious-code mechanism qualification |
| OPC 30081 (PA-DIM) (inline-only — no detail doc) | OPC UA Process Automation Device Information Model | High | Subset | 6 types registered (PADIMType + 5 Signal* subtypes); BrowseNames match spec exactly. 4 PADIMType children over-claim Mandatory vs spec Optional -- fix tracked |
| OPC 40223 (Pumps) (inline-only — no detail doc) | OPC UA for Pumps and Vacuum Pumps | Moderate | Subset | PumpType registered with 7 group children at exact spec BrowseNames; leaf properties intentionally read live from server. VacuumPumpType deferred |
| OPC 40080 (Process Valves) (inline-only — no detail doc) | OPC UA for Process Valves (purported) | -- | N/A | Spec not published by OPC Foundation; absence verified and tested |
Status Legend¶
| Indicator | Meaning |
|---|---|
| Implemented | Requirement is fully implemented with tests and evidence |
| Substantially Implemented | Majority of requirements met; named gaps remain, documented per-clause in the matrix |
| Partial | Core functionality exists but gaps remain |
| Planned | Architecture is designed but implementation has not started |
| N/A | Requirement does not apply to this system |
Document Structure¶
Traceability documents share a common shape, though not every document carries every section (e.g., some omit a standalone Gap Analysis or Roadmap when the matrix rows themselves carry the gap status). The typical sections:
- Header -- Standard name, version, and applicability scope
- Requirements tables -- Requirement, Status, and Implementation evidence (column layout varies by standard)
- Gap analysis -- Honest assessment of what is not yet implemented
- Roadmap -- Planned work to close gaps
Each per-standard document is authoritative for its own structure and status detail. This index summarizes.
Supporting Documents¶
- Secure Development Lifecycle Audit File — the
development lifecycle assembled as one audit-consumable file, mapped to the
eight practice areas and 47 requirements of IEC 62443-4-1, with an evidence
column naming what an auditor can inspect for each. Written for a customer
quality unit running a GAMP 5 supplier assessment and for an ISASecure SDLA
assessor. The 4-1 assessment is its internal counterpart,
and
make lint-sdl-audit-parityholds the two to identical dispositions. - Executable Validation Protocols (IQ/OQ/PQ) — architectural
overview of
dcs qualify {iq,oq,pq}, the executable replacement for blank IQ/OQ/PQ templates. Referenced from the 21 CFR Part 11 §11.10(a) row. - DR Drill Log — Audit Archive Corruption (2026-04-22): evidence artifact for the 21 CFR Part 11 §11.10(c) restore-path qualification (archive tamper detection, immutable S3 mirror restore).
- DR Drill Log — Certificate Expiry (2026-04-22): evidence artifact for the certificate-expiry DR scenario referenced from the IEC 62443 SL-3 operator checklist.
- DR Drill Log — Backup/Restore (2026-07-18): evidence artifact for IEC 62443 SR/CR 7.3 RE(1): backup → pre-restore integrity verification (tamper + truncation detection) → restore, incl. the restore-path defect the drill caught and fixed (#973).
Related Documentation¶
The documents in this directory are formal traceability matrices for the regulated standards Cloud-Native DCS is being qualified against (ISA-88, ISA-95, IEC 61131-3, ISA 5.1, IEC 62443, 21 CFR Part 11). For the adjacent modular automation reference standards that describe our role as a plant-level orchestrator, VDI/VDE/NAMUR 2658 (MTP), IEC 63280, NAMUR NE 148, and NAMUR NE 175 (NOA), see the Modular Automation Standards section. Those documents describe architectural alignment with industry standards. Clause-by-clause regulatory traceability stays in this directory.
